CZone Drop Cable Assembly (0.5m – 5m)
The CZone Drop Cable Assembly is a high-performance, marine-grade network cable engineered to connect digital switching modules, displays, interfaces, and smart sensors directly to a CZone or NMEA 2000 (N2K) network backbone. Featuring standardized 5-pin Micro-C connectors (male on one end, female on the other), these cables provide reliable, high-speed data transmission across intelligent marine electrical systems.
Built for harsh marine and mobile environments, each cable is constructed with fine-stranded tinned copper conductors, shielded pairs to eliminate signal interference, and a UV-resistant, flame-retardant outer jacket. Available in six standardized lengths from 0.5 meters to 5.0 meters, these cables simplify helm wiring and ensure clean, clutter-free console installations.
Key Features
-
Plug-and-Play Integration: Bridges CZone digital control modules (COI, SCI, SI, Signal Interface) directly into standard network T-connectors.
-
Micro-C Universal Standard: Universal 5-pin threaded connector interface ensures full cross-compatibility with NMEA 2000 and CAN bus networks.
-
Corrosion-Resistant Tinned Conductors: Fine-stranded, tinned copper wiring offers exceptional conductivity and maximum resistance against salt spray corrosion.
-
Dual Shielded Architecture: Shielded twisted pair construction prevents signal attenuation, crosstalk, and electromagnetic interference (EMI) from engine alternators.
-
IP67 Submersible Protection: Molded strain-relief connectors equipped with heavy-duty locking nuts and internal O-rings form a dust-tight, waterproof seal.
