NMEA 2000 Extension Cable Assembly (0.5m – 10m)
The NMEA 2000 Extension Cable Assembly is a heavy-duty, marine-grade cabling solution engineered to extend backbones and drop line connections across NMEA 2000 (N2K) CAN bus data networks. Equipped with standard Micro-C 5-pin connectors—male on one end and female on the other—this cable facilitates reliable, high-speed data transmission between marine instruments, chartplotters, transducers, sensors, and display units.
Built to withstand severe marine environments, each cable features fine-stranded tinned copper conductors, power and data pair shielding, and a durable UV-resistant PVC outer jacket to ensure lossless signal integrity and immunity from electromagnetic interference (EMI).
Key Features
-
Plug-and-Play Micro-C Connectivity: Universal 5-pin male to female threaded connectors plug directly into standard NMEA 2000 T-connectors, multiport taps, and device ports.
-
Dual-Shielded Anti-Interference Architecture: Shielded twisted pair construction protects critical data lines from RF interference and engine noise.
-
Marine-Grade Tinned Copper Conductors: Fine-stranded, tinned copper wiring delivers maximum conductivity and superior corrosion resistance against salt mist and moisture.
-
IP67 Submersible Waterproofing: Molded connector strain reliefs with internal O-ring seals prevent water ingress even when submerged or exposed to heavy washdowns.
-
Flexible Installation Options: Available in standard lengths from 0.5 m to 10.0 m to eliminate excess cable clutter and minimize line loss across the backbone.
